Speaker |
Microphone |
| Type |
Magnetic |
Magnetic |
| Impedance |
1850Ω |
| Sound Pressure Level |
123dB |
- |
| Nominal Input Power |
10mW |
- |
| Sensitivity |
- |
-51dB |
| At |
0dB=2×10-5Pa |
0dB=1V/0.5Pa |
Weight
(excluding Plug & Cord) |
Approx 4gr |
| Measuring Conditions |
IEC 711 Coupler |
25mm distance |
|
|
|
 |
 |
 |
 |
|
|
|
|
 |
|
|
|
